Free course · PLC programming
Allen-Bradley Micro800 with Connected Components Workbench
This free course teaches the Allen Bradley Micro820 and Micro850 PLCs in Connected Components Workbench: wiring, the simulator, ladder, function block and structured text, timers, counters, analog signals, high-speed counters, motion and Modbus TCP. It suits UK electricians, maintenance technicians and apprentices, and helps with PLC programmer and controls technician roles. Micro800 controllers run small machines, and a migration module helps if your site still has MicroLogix.
Allen-Bradley Micro800 with Connected Components Workbench is a free online beginner PLC programming course with 16 modules, about 20 hours of video lessons. Learning is free; an optional verifiable certificate costs £19 including VAT when you pass the final exam. Last updated 28 October 2026.
Free to learn. Verifiable certificate £19 when you pass the final exam (optional, VAT included).

Sample certificate. Optional, issued when you pass the final exam.
- Level
- Beginner
- Modules
- 16
- Video
- 20 hours
- Price
- Free
Video time only: reading the notes, the quizzes and the final exam take extra time, at your own pace.
Outcome
What you will be able to do
Install and activate CCW, wire a Micro820/850, connect, upload, download and update firmware, build LD, FBD and ST projects with an HMI, use bit logic, latching, retentive outputs, timers, counters and analog scaling, write UDFBs, read encoders on the HSC, do PTO motion, message drives and Logix controllers, serve Modbus TCP, use trends, PID and data logs, and migrate MicroLogix programs.
- Install CCW, activate it and run the Micro800 Simulator
- Wire a Micro820/850, fix IP problems, upload, download and update firmware
- Build the same logic in LD, FBD and ST with a PanelView 800 HMI
- Use bit instructions, latching, retentive outputs, timers and counters
- Wire and scale 0-10 V and 4-20 mA signals
- Write UDFBs and UDFs and read encoders on the HSC
- Run PTO stepper and servo motion
- Message PowerFlex 525 drives and Logix controllers, serve Modbus TCP, use PID and trends, migrate MicroLogix
Software
Connected Components Workbench Standard (free) with the Micro800 Simulator
Hardware
None required. A Micro820 trainer makes wiring, analog and motion real.
Syllabus
16 modules
Each module has video lessons, notes and a short quiz. The final exam closes the course.
- Micro800, CCW and the Simulator6 lessons
- Wiring the Micro820 and Micro8505 lessons
- Connecting, Uploading, Downloading, Firmware10 lessons
- CCW Projects: LD, FBD, ST and an HMI4 lessons
- Scan Cycle and Bit Instructions3 lessons
- Latching, Set/Reset, Retentive Outputs5 lessonsLab
- Timers3 lessonsLab
- Counters2 lessonsLab
- Analog4 lessonsLab
- UDFBs, UDFs and Documentation7 lessons
- High-Speed Counter and Encoders4 lessons
- Motion: PTO Stepper and Servo5 lessonsLab
- Communications: Drives, Logix, Modbus TCP, Modules8 lessonsLab
- Trends, PID, Data Logs, Protection, Faults7 lessonsLab
- Migration and Modernisation7 lessons
- Final Assessment1 lesson
How it works
How this course works
- Watch the video lessonsOne module at a time, at your own pace.
- Take the module quizA short quiz at the end of each module shows what stuck.
- Keep your notesWrite in My notes beside each module and ask the trainer if you are stuck.
- Practise in the labOptionalTry a task from the module in the EDWartens Lab, in your browser.
- Sit the final examPass it once you have been through the modules.
- Certificate, if you want oneOptionalPaid, and only after you pass. Anyone can check it online.
EDWartens Lab
Practise this in the EDWartens Lab
Write and test the same ladder logic in the Lab's PLC simulator, go online and force inputs. The Lab uses a vendor-neutral editor, so brand software stays in the course.
Works alongside Allen-Bradley Micro800 with Connected Components Workbench. The Lab is plc programming practice in your browser: no install, no hardware, free to use. Sign in as a learner and it opens with your account.
Levels to try with this course
PLC-01 · PLC lab
Motor start/stop with overload
Open in the lab (opens in a new tab)PLC-02 · PLC lab
Forward/reverse conveyor
Open in the lab (opens in a new tab)PLC-04 · PLC lab
Batch counter on a packing line
Open in the lab (opens in a new tab)Electrical lab
Commission the 4-20 mA level loop
Open in the lab (opens in a new tab)
Optional. Skip it whenever you like: it never blocks your progress or your certificate.
Why practise in a lab
Technical work is judged on what you can do: wiring, commissioning, finding a fault. Doing a task yourself teaches more than watching it a second time, and a lab lets you try it safely before you meet real equipment. It does not replace working on real hardware.
- Practise safely, so a mistake costs nothing.
- The lab checks your work like a site test, so you know when it is right.
- Free, in your browser, with nothing to install.
Certificate
An optional certificate when you pass
Learning is free. Pass the final exam and you can have a certificate for £19, including VAT, with a number employers can check online. It records that you completed a free online course; it is not a regulated qualification or a CPD certificate.
- Your name, the course, its study time and your final exam score
- A unique certificate number and a QR code to its verification page
- Issued by Wartens Ltd; add it to your LinkedIn profile in one click
- Pay now or after you pass: it is issued the moment you pass the final

Credits
Who made the lessons
The video lessons belong to their creators. EDWartens wrote the study plan, notes, quizzes and the final exam.
- Rockwell Automation
the official Connected Components Workbench tutorials
- Tim Wilborne
the Micro800 CCW course lessons
Jobs
Jobs this course can lead to
The skills in this course are used in PLC and industrial automation work, for example as a PLC programmer, a controls technician and a maintenance technician. No course can promise a job, and employers also look for experience, so read what live adverts ask for.
Browse PLC and industrial automation jobs
454 jobs live on the UK board
Browse PLC programmer jobs
53 jobs live on the UK board
Pay: Advertised PLC engineer roles show a median of £60,000, with 147 permanent adverts in the six months to 27 October 2026 against 80 a year earlier. Source: ITJobsWatch (advert-based, an IT-category sample). Checked 27 Oct 2026.
Questions
About this course
Last reviewed 28 October 2026.
Do I need a Micro820 to follow the course?
Is this useful if my site still runs MicroLogix?
Is the certificate recognised?
What does the Allen-Bradley Micro800 with Connected Components Workbench course cover?
Where does Allen-Bradley Micro800 with Connected Components Workbench start and where does it end?
How long is Allen-Bradley Micro800 with Connected Components Workbench?
Can I practise Allen-Bradley Micro800 with Connected Components Workbench in the browser?
Is CCW free?
Do I need a Micro800?
Micro800 versus MicroLogix?
Is the course really free?
What certificate do I get, and is it a Rockwell Automation qualification?
Who made the video lessons?
How long does the course take?
