Free course · PLC programming

Eaton easyE4 Control Relay with easySoft

This free course teaches the Eaton easyE4 control relay and easySoft programming in ladder, function block diagram, structured text and EDP, plus PID, touch displays, Ethernet, Modbus RTU and MQTT. It suits UK electricians, maintenance technicians, apprentices and small machine builders who meet smart relays on pumps, HVAC plant and cold rooms. It helps with controls technician and junior PLC programming work. No hardware is needed, because the easySoft free edition simulates your programs.

Eaton easyE4 Control Relay with easySoft is a free online beginner PLC programming course with 8 modules, about 10 hours of video lessons. Learning is free; an optional verifiable certificate costs £19 including VAT when you pass the final exam. Last updated 28 October 2026.

See the modules

Free to learn. Verifiable certificate £19 when you pass the final exam (optional, VAT included).

Level
Beginner
Modules
8
Video
10 hours

Video time only: reading the notes, the quizzes and the final exam take extra time, at your own pace.

Price
Free

Outcome

What you will be able to do

Explain where an easyE4 fits, program in LD, FBD, ST and EDP, set system functions and connect over Ethernet, use function blocks including user blocks, PID and PWM, connect displays, communicate over SmartWire-DT, Modbus RTU, MQTT and AWS, and log data.

  • Know control relays, the easyE4 range and its features
  • Install easySoft and program in LD, FBD, ST and EDP
  • Set system functions and connect over Ethernet
  • Use function blocks, user function blocks, PID and PWM
  • Connect remote touch displays and XV panels and build visualisation
  • Communicate over SmartWire-DT, Modbus RTU, MQTT and AWS
  • Log data with the ring-buffer data logger and apply easyE4 to cold rooms

Software

easySoft 8: the free edition simulates your programs; loading one onto a real easyE4 needs a paid licence

Hardware

None required.

Syllabus

8 modules

Each module has video lessons, notes and a short quiz. The final exam closes the course.

  1. 1easyE4 and Control Relays10 lessons
  2. 2easySoft: Install, Licensing and Languages7 lessonsLab
  3. 3System Settings and Ethernet3 lessons
  4. 4Function Blocks, User Blocks, PID and PWM6 lessonsLab
  5. 5Displays and Visualisation4 lessonsLab
  6. 6Communication: SmartWire-DT, Modbus RTU, MQTT and AWS5 lessonsLab
  7. 7Data Logger and Applications3 lessonsLab
  8. 8Final Assessment1 lesson

How it works

How this course works

  1. Watch the video lessonsOne module at a time, at your own pace.
  2. Take the module quizA short quiz at the end of each module shows what stuck.
  3. Keep your notesWrite in My notes beside each module and ask the trainer if you are stuck.
  4. Practise in the labOptionalTry a task from the module in the EDWartens Lab, in your browser.
  5. Sit the final examPass it once you have been through the modules.
  6. Certificate, if you want oneOptionalPaid, and only after you pass. Anyone can check it online.

EDWartens Lab

Practise this in the EDWartens Lab

Write and test the same ladder logic in the Lab's PLC simulator, go online and force inputs. The Lab uses a vendor-neutral editor, so brand software stays in the course.

Works alongside Eaton easyE4 Control Relay with easySoft. The Lab is plc programming practice in your browser: no install, no hardware, free to use. Sign in as a learner and it opens with your account.

PLC programming: Program a PLC, see it run.

Levels to try with this course

Optional. Skip it whenever you like: it never blocks your progress or your certificate.

Why practise in a lab

Technical work is judged on what you can do: wiring, commissioning, finding a fault. Doing a task yourself teaches more than watching it a second time, and a lab lets you try it safely before you meet real equipment. It does not replace working on real hardware.

  • Practise safely, so a mistake costs nothing.
  • The lab checks your work like a site test, so you know when it is right.
  • Free, in your browser, with nothing to install.

Certificate

An optional certificate when you pass

Learning is free. Pass the final exam and you can have a certificate for £19, including VAT, with a number employers can check online. It records that you completed a free online course; it is not a regulated qualification or a CPD certificate.

  • Your name, the course, its study time and your final exam score
  • A unique certificate number and a QR code to its verification page
  • Issued by Wartens Ltd; add it to your LinkedIn profile in one click
  • Pay now or after you pass: it is issued the moment you pass the final

How the certificate works

Sample certificate for Eaton easyE4 Control Relay with easySoft

Credits

Who made the lessons

The video lessons belong to their creators. EDWartens wrote the study plan, notes, quizzes and the final exam.

  • Eaton

    the official easyE4 and easySoft English tutorials

Jobs

Jobs this course can lead to

The skills in this course are used in PLC and industrial automation work, for example as a PLC programmer, a controls technician and a maintenance electrician. No course can promise a job, and employers also look for experience, so read what live adverts ask for.

Pay: Advertised PLC engineer roles show a median of £60,000, with 147 permanent adverts in the six months to 27 October 2026 against 80 a year earlier. Source: ITJobsWatch (advert-based, an IT-category sample). Checked 27 Oct 2026.

Questions

About this course

Last reviewed 28 October 2026.

Is easySoft free to use for this course?
The free edition of easySoft 8 simulates your programs, so you can complete the course without hardware. Loading a program onto a real easyE4 needs a paid version from Eaton. Module 2 covers installation and licensing, and you should check Eaton's current terms before buying anything.
Will the easyE4 help me become a PLC programmer in the UK?
It is a useful first step on a small controller, and the logic ideas carry across to larger PLCs. UK employers usually also ask for experience on mainstream PLC platforms, so treat this as a foundation alongside a Siemens or Rockwell course, not a complete route into the role.
Is the certificate an Eaton qualification?
No. The £19 inc VAT certificate comes from EDWartens, is optional and confirms that you completed the course. It is not an Eaton qualification, not a regulated qualification and not accredited. The learning itself is free to follow at your own pace.
What does the Eaton easyE4 Control Relay with easySoft course cover?
It has 8 modules. The first are “easyE4 and Control Relays”, “easySoft: Install, Licensing and Languages”, “System Settings and Ethernet”, “Function Blocks, User Blocks, PID and PWM” and “Displays and Visualisation”, and 3 more follow. Each module has video lessons, notes and a short quiz.
Where does Eaton easyE4 Control Relay with easySoft start and where does it end?
It starts with “easyE4 and Control Relays” and the last module is “Final Assessment”. The final exam closes the course, and passing it is what makes the optional £19 certificate available.
How long is Eaton easyE4 Control Relay with easySoft?
8 modules with 39 lessons, about 10 hours of video lessons. The largest module is “easyE4 and Control Relays” with 10 lessons. Video time only: reading the notes, the quizzes and the final exam take extra time, at your own pace.
Can I practise Eaton easyE4 Control Relay with easySoft in the browser?
Yes. Some modules of Eaton easyE4 Control Relay with easySoft have a practice level in the EDWartens Lab, marked Lab on the module list, so you can try the ideas in your browser without installing software.
Is easySoft free?
Yes to download and simulate; a licence is needed only to download to a physical easyE4.
easyE4 or Siemens LOGO!?
Both are control relays for small tasks. An easyE4 base takes up to 11 plug-in expansion modules and an optional SmartWire-DT coordinator module; compare the current data sheets of both before you choose. The free LOGO! course covers the other one.
Are all lessons official?
Yes, all from Eaton's English channel.
Is the course really free?
Yes. Every module, practice task and assessment. You create an account so your progress is saved and the assessments can be marked. The certificate is the only paid item, and only if you want it.
Who made the video lessons?
The creators named in the Credits block at the foot of this page, on their own YouTube channels. EDWartens did not make the videos and the creators are not affiliated with EDWartens. What EDWartens wrote is the study plan, the notes, the practice tasks and the assessments.
How long does the course take?
Plan on about 10 hours in all, including the video lessons, notes and practice tasks. It is self-paced, so you work through the eight modules at your own speed.
