Free course · Robotics

ABB Robot Programming with RobotStudio and RAPID

RobotStudio from install to a running pick-and-place: stations, jogging, the FlexPendant, frames, paths, RAPID, collision checking, signals, physics, sharing and RobotStudio Cloud.

See the modules

Free to learn. Verifiable certificate £19 when you pass the final exam (optional, VAT included).

Level
Beginner
Modules
16
Video
17 hours
Price
Free

Outcome

What you will be able to do

Install RobotStudio and build a station, jog and use the virtual FlexPendant, define tool and work-object frames, attach grippers, create paths and targets, write RAPID for motion and pick-and-place, check collisions, simulate signals and physics, share stations and collaborate in RobotStudio Cloud, and explain inverse kinematics.

  • Build a station with a robot and a virtual controller
  • Jog with the mouse and the virtual FlexPendant in every motion mode
  • Define tooldata and wobjdata and know why the program follows the frame
  • Attach a gripper, create targets and paths, check reachability
  • Write RAPID: MoveJ, MoveL, zones, speeds, signals, Offs, loops and procedures
  • Set up collision checking and fix a path until it runs clean
  • Simulate signals, events, physics and mechanisms
  • Share stations with Pack and Go and collaborate in RobotStudio Cloud

Software

ABB RobotStudio with a virtual controller: a 30-day trial of the full version. After it, Basic mode still runs the virtual controller but not the offline programming and simulation tools, so plan to finish inside the trial

Hardware

None. The virtual controller runs every exercise.

Syllabus

16 modules

Each module has video lessons, notes and a short quiz. The final exam closes the course.

  1. 1RobotStudio: Getting Started6 lessons
  2. 2Navigating and Jogging in the Station3 lessonsLab
  3. 3The FlexPendant3 lessonsLab
  4. 4Tool and Work-Object Frames4 lessonsLab
  5. 5Grippers and End Effectors3 lessons
  6. 6Paths and Targets4 lessonsLab
  7. 7RAPID: Introduction2 lessons
  8. 8Pick and Place in RAPID4 lessonsLab
  9. 9Collision Avoidance and Checking5 lessons
  10. 10Signals, Events and the Signal Analyzer2 lessons
  11. 11Physics, Mechanisms and Cables4 lessons
  12. 12Sharing Stations and Add-Ins5 lessons
  13. 13RobotStudio Cloud8 lessons
  14. 14Kinematics Background2 lessons
  15. 15Recording, Envelopes and AR4 lessons
  16. 16Final Assessment1 lesson

How it works

How this course works

  1. Watch the video lessonsOne module at a time, at your own pace.
  2. Take the module quizA short quiz at the end of each module shows what stuck.
  3. Keep your notesWrite in My notes beside each module and ask the trainer if you are stuck.
  4. Practise in the labOptionalTry a task from the module in the EDWartens Lab, in your browser.
  5. Sit the final examPass it once you have been through the modules.
  6. Certificate, if you want oneOptionalPaid, and only after you pass. Anyone can check it online.

EDWartens Lab

Practise this in the EDWartens Lab

Jog an arm with a pendant, teach points and run a pick and place cycle in the Lab's robot simulator.

Works alongside ABB Robot Programming with RobotStudio and RAPID. The Lab is robot cell practice in your browser: no install, no hardware, free to use. Sign in as a learner and it opens with your account.

Open the free lab See the Lab
Robot cell: Teach a robot arm.

Levels to try with this course

Optional. Skip it whenever you like: it never blocks your progress or your certificate.

Why practise in a lab

Technical work is judged on what you can do: wiring, commissioning, finding a fault. Doing a task yourself teaches more than watching it a second time, and a lab lets you try it safely before you meet real equipment. It does not replace working on real hardware.

  • Practise safely, so a mistake costs nothing.
  • The lab checks your work like a site test, so you know when it is right.
  • Free, in your browser, with nothing to install.

Certificate

An optional certificate when you pass

Learning is free. Pass the final exam and you can have a certificate for £19, including VAT, with a number employers can check online. It records that you completed a free online course; it is not a regulated qualification or a CPD certificate.

  • Your name, the course, its study time and your final exam score
  • A unique certificate number and a QR code to its verification page
  • Issued by Wartens Ltd; add it to your LinkedIn profile in one click
  • Pay now or after you pass: it is issued the moment you pass the final

How the certificate works

Sample certificate for ABB Robot Programming with RobotStudio and RAPID

Credits

Who made the lessons

The video lessons belong to their creators. EDWartens wrote the study plan, notes, quizzes and the final exam.

Questions

About this course

Is RobotStudio free?
For 30 days, yes: ABB gives a full-featured trial. After it, the free Basic mode still runs the virtual controller, but the offline programming and simulation tools this course uses need a licence, so plan the modules into the trial window.
Do I need an ABB robot?
No. The virtual controller and FlexPendant behave like the real ones; a program written here loads onto a real IRC5 or OmniCore controller.
Which controllers does this cover?
IRC5 and OmniCore through RobotWare 6 and 7. The RAPID language is the same.
Some source lessons are members-only. Are they included?
No. Four members-only lessons were left out and their topics are covered by public lessons.
Is the course really free?
Yes. Every module, practice task and assessment. You create an account so your progress is saved and the assessments can be marked. The certificate is the only paid item, and only if you want it.
What certificate do I get, and is it a ABB qualification?
An EDWartens Certificate of Completion, issued when you pass the final assessment, with a verification code anyone can check. It is not a ABB credential and is never described as one.
Who made the video lessons?
The creators named in the Credits block at the foot of this page, on their own YouTube channels. EDWartens did not make the videos and the creators are not affiliated with EDWartens. What EDWartens wrote is the study plan, the notes, the practice tasks and the assessments.
