What Is SCADA? Architecture, Protocols, Platforms, UK Uses

SCADA (supervisory control and data acquisition) is a control system architecture that lets operators monitor and control machines and processes from a central point, using field controllers, communications, servers, operator screens and a historian. ITJobsWatch counted 632 UK permanent adverts mentioning SCADA in the six months to 21 October 2026, with a median salary of £55,000.

SCADAindustrial automationWinCCIgnitionOT securityengineering guide
Woman at a control desk with several monitors, facing a dark curved screen wall in a control room

Key takeaways

  • SCADA is a control system architecture that supervises many PLCs and RTUs from a central point, with servers, operator screens and a historian.
  • ITJobsWatch counted 632 UK permanent adverts mentioning SCADA in the six months to 21 October 2026, with a median salary of £55,000 (10th to 90th percentile: £39,500 to £80,000).
  • The UK NIS Regulations 2018 apply to essential services in transport, energy, water, health and digital infrastructure.
  • The NCSC's secure connectivity guidance sets eight principles, including limiting exposure, using secure protocols and having an isolation plan.
  • Common SCADA protocols include Modbus, DNP3, IEC 60870-5-104, IEC 61850 and OPC UA; the NCSC recommends secure versions such as DNP3-SAv5 and OPC UA over OPC DA.

SCADA is a control system architecture that combines computers, networked communications and graphical interfaces to supervise machines and processes. Field devices and controllers (PLCs or RTUs) do the real-time control; the SCADA layer collects their data, shows it to operators, stores history and sends supervisory commands. In the UK it is most visible in water, energy and transport. According to ITJobsWatch, 632 UK permanent adverts mentioned SCADA in the six months to 21 October 2026, with a median advertised salary of £55,000.

What is SCADA, and how is it different from a PLC or HMI?

SCADA supervises many controllers across a plant or region; a PLC controls one machine or process area; an HMI is the operator screen. A PLC reads inputs, runs logic and drives outputs in a fast scan cycle. SCADA sits above, polling many PLCs and remote terminal units (RTUs), presenting mimic diagrams, alarms and trends, and logging data. An HMI on a single machine is a local operator panel, whereas a SCADA client is one window onto the whole system. The related guide PLC vs SCADA explained goes further.

PLCHMISCADA
Main jobReal-time control logicOperator screen for a machine or areaSupervision of many controllers, alarms, history
ScaleOne machine or cellOne machine or areaSite, plant or region
Data storageLittleLimitedHistorian and database
Typical userControls engineerOperatorOperator, engineer, management

The NCSC describes SCADA as the basis for data collection and control across critical national infrastructure and other cyber-physical systems, monitoring and controlling distributed physical assets with real-world effects.

How is a SCADA system built?

A SCADA system has four parts: field devices and controllers, communications, a supervisory layer, and the operator interface with a historian. The arrangement below follows the levels commonly used to describe SCADA architecture.

LayerComponentsWhat it does
Field level (Level 0)Sensors, valves, drives, motorsMeasure and act on the physical process
Control level (Level 1)PLCs, RTUs, I/O modulesRun local control; RTUs are common at remote sites
CommunicationsEthernet, fibre, radio, cellular, serial linksCarry data between sites and the control centre
Supervisory level (Level 2)SCADA servers (often redundant), HMI clients, historian, alarm systemCollect data, show mimics, alarms and trends, store history
Business level (Levels 3 and 4)Production control and scheduling, enterprise systemsUse SCADA data for reporting and planning

Two design points matter in practice. First, field controllers keep running on their last command if communications fail, so local control does not depend on the link. Second, web-based SCADA now lets users reach the system through standard browsers, which is convenient and also increases the security burden. For a hands-on view of the supervisory layer, try the free Siemens WinCC SCADA course.

What is SCADA?

Which protocols do SCADA systems use?

SCADA links use a mix of legacy and standard protocols, with OPC UA increasingly used as a vendor-neutral interface. The protocols you meet depend on the sector and the age of the installation.

ProtocolWhere you meet itNotes
Modbus (RTU and TCP)Older and simple device linksWidely supported; NCSC advises moving to secure versions where available
DNP3Utilities and telecontrolOne of the standard protocols; NCSC points to DNP3-SAv5 as the secure version
IEC 60870-5-101/104 and IEC 61850Power system telecontrol and substationsStandard grid protocols
EtherNet/IP and PROFINETPlant-floor networksBetween PLCs and I/O; NCSC suggests confining industrial control protocols to isolated OT segments
OPC UAConnecting SCADA to controllers and IT systemsNCSC recommends OPC UA over OPC DA; see OPC UA explained

Where is SCADA used in the UK?

SCADA runs the essential services the UK treats as critical. The government's NIS Regulations 2018 apply to essential services in transport, energy, water, health and digital infrastructure, so operators in those sectors have formal security duties. The NCSC's operational technology guidance includes a (fictional) worked example of a regional water utility whose central control room monitors treatment sites through a regional SCADA system collecting data from RTUs.

A water treatment plant control room at Tophill Low, East Riding of Yorkshire
A water treatment plant control room at Tophill Low, East Riding of YorkshirePhoto: Gordon Kneale Brooke, CC BY-SA 2.0, via Wikimedia Commons

Typical uses include:

  • Water and wastewater: pumping stations, reservoirs, treatment works, with remote sites reporting via RTUs. See the water industry automation career guide.
  • Energy and utilities: substations, distribution networks and generation sites.
  • Manufacturing: line supervision, batch records, shift reporting and alarm management. In smaller plants a plant-wide SCADA often sits on top of several PLC-based machines.
  • Transport and buildings: monitoring and control of infrastructure and building services.

What are the main SCADA platforms?

You will most often meet Siemens WinCC, Inductive Automation's Ignition, Rockwell's FactoryTalk software and AVEVA (formerly Wonderware) in UK work, and the right one depends on the site's PLC brand.

PlatformVendorWhat it is
WinCC Unified (PC)SiemensSCADA software that lives in TIA Portal; Siemens also lists redundant SCADA, ISA-88 batch and recipe control, and a Data Hub for long-term archiving
IgnitionInductive AutomationServer software that acts as a hub connecting to plant equipment and SQL databases; web-deployed clients; the vendor advertises unlimited tags, clients and designers on one flat-rate licence and a free-to-try download with no time limit
FactoryTalk suiteRockwell AutomationRockwell's software suite alongside Studio 5000 and Logix controllers
AVEVA (InTouch, System Platform)AVEVASCADA and HMI products, formerly branded Wonderware; EDWartens has a free InTouch course

On pay, the ITJobsWatch SCADA figures for the six months to 21 October 2026 were: median £55,000, 10th percentile £39,500, 90th percentile £80,000, from 247 quoted salaries. WinCC alone had only 23 permanent adverts (median £47,500), a sample too small to lean on. The index leans towards IT roles, so treat it as indicative. For platform choice, see WinCC vs Ignition for SCADA training and the SCADA beginner's tutorial.

How do you secure a SCADA system?

Security for SCADA starts from the fact that OT prioritises safety, reliability and availability, not just confidentiality. The NCSC's operational technology guidance stresses that connecting OT to enterprise networks and the internet can add vulnerabilities, and that the NIS Regulations apply to critical national infrastructure.

Its Secure connectivity principles for OT, produced with international partners, set eight principles:

  1. Balance the risks and opportunities.
  2. Limit the exposure of your connectivity.
  3. Centralise and standardise network connections.
  4. Use standardised and secure protocols.
  5. Harden your OT boundary.
  6. Limit the impact of compromise.
  7. Ensure all connectivity is logged and monitored.
  8. Establish an isolation plan.

Concrete measures in that guidance include initiating connections outbound from within the OT environment to avoid exposed inbound ports, using brokered connections through a DMZ for outside access, and defaulting to the latest secure protocol versions. The NCSC also publishes guidance on cloud-hosted SCADA, which it says fundamentally changes security boundaries and access control compared with legacy air-gapped systems. You can explore these ideas in the free OT security simulator and in our piece on AI and cybersecurity for industrial control systems.

A SCADA room at a water plant, with operator workstations and wall displays
A SCADA room at a water plant, with operator workstations and wall displaysPhoto: Z22, CC BY-SA 4.0, via Wikimedia Commons

How do you learn SCADA?

Learn PLCs first, because SCADA depends on controller data and tag structures, then add one platform in depth. Practise screens, tags, alarms, trends and a small historian project on a free tool. Free courses cover Siemens WinCC, Ignition and Wonderware InTouch. For a career view, read the SCADA engineer career path.

How EDWartens can help

The Professional Module includes WinCC SCADA on days four and five of the five-day live online class, covering tags, graphics, animation, alarms and events, and trending and historical data, after PLC and HMI work in TIA Portal. It is £2,140 + VAT (£2,568), with a £100 deposit option and a maximum of 10 learners per cohort, starting every Monday. It is Siemens-focused and delivered online with simulation, so it does not cover Ignition or AVEVA; use the free courses for those. Sign up here.

Start free

Learn SCADA and HMI free, then practise the job

Free job simulation

SCADA and HMI Engineer

Build the tag list, alarm list and screens for a live process.

The first five days are free, no card needed.

Live UK jobs

SCADA and HMI jobs in the UK

Updated daily, with licensed visa sponsors marked.

Browse all engineering jobs

Frequently asked questions

What does SCADA stand for?

SCADA stands for supervisory control and data acquisition. It is a control system architecture that combines computers, networked communications and graphical interfaces so operators can supervise machines and processes, collect data, view alarms and trends, and issue supervisory commands, while PLCs or RTUs handle the real-time control in the field.

What is the difference between SCADA and a PLC?

A PLC is a controller that runs real-time logic for a machine or process area. SCADA sits above many PLCs and RTUs to collect their data, display it, raise alarms and store history. PLCs keep controlling if communications to the SCADA server fail, so SCADA supervises rather than replaces them.

Which SCADA software should I learn?

Choose according to the PLC brand and employers you are targeting. Siemens WinCC fits Siemens environments, Ignition is a popular server-based platform, and Rockwell sites use FactoryTalk. ITJobsWatch showed 632 UK permanent SCADA adverts in the six months to 21 October 2026, so learning one platform well is a sensible start.

How much do SCADA engineers earn in the UK?

ITJobsWatch reported a median advertised salary of £55,000 for UK permanent roles mentioning SCADA in the six months to 21 October 2026, with a 10th percentile of £39,500 and a 90th of £80,000. It is an IT-leaning index with a limited number of quoted salaries, so treat it as a guide.

Is SCADA secure?

It can be, but only if designed that way. The NCSC says connecting OT to enterprise networks and the internet can add vulnerabilities, and OT prioritises safety, reliability and availability. Its guidance recommends limiting exposure, avoiding inbound ports, using a DMZ, moving to secure protocol versions, logging connections and planning for isolation.
