IO-Link Explained: Smart Sensors, IODD and PLC Integration

IO-Link (IEC 61131-9) is a point-to-point link that turns ordinary 3-wire sensors and actuators into devices that report diagnostics and accept remote settings. PI counts 71 million installed IO-Link nodes after 9.7 million new in 2025. Here is how it works, what an IODD is and how it reaches the PLC.

IO-LinkSmart SensorsIODDIndustry 4.0DiagnosticsPROFINET
Electrician in a blue hard hat checking wiring inside a tall industrial control cabinet

Key takeaways

  • IO-Link is standardised as IEC 61131-9 and is point-to-point, not a fieldbus.
  • PI reports about 9.7 million IO-Link nodes installed in 2025, for a worldwide total of 71 million.
  • It uses standard 3-wire cable, three speeds (4.8, 38.4 and 230.4 kbaud) and a maximum cable length of 20 metres.
  • The IODD file describes each device's identity, parameters and process data for automatic configuration.
  • IO-Link Safety (up to SIL 3) and IO-Link Wireless both arrived in 2022; Smart Sensor Profile 1.2 was published on 1 January 2024.

IO-Link is the first globally standardised IO technology (IEC 61131-9) for communicating with sensors and actuators. Unlike a fieldbus, it is a point-to-point link between one device and one port on an IO-Link master, using the same three-wire cable as a conventional sensor. PI reports that about 9.7 million IO-Link nodes were installed in 2025, taking the worldwide total to 71 million.

IO-Link is not a fieldbus; it is the last metre between a field device and the control system. The IO-Link community states that it is the evolutionary development of the established three-wire sensor connection, with no special cable material required. A device plugs into a port on an IO-Link master. The master then talks to the PLC over whichever fieldbus or industrial Ethernet the plant uses, so IO-Link is fieldbus independent.

Key facts from the IO-Link community and the IEC standard:

  • Cable and connectors. Standard M12, M8 or M5 connectors and unscreened three-wire cable. Wikipedia notes cable length is limited to 20 metres and defines two port classes: class A (up to four pins) and class B (five-pin M12 with an additional power supply).
  • Speeds. Three transmission rates: 4.8, 38.4 and 230.4 kbaud.
  • Ecosystem. The community cites more than 500 manufacturers and 20,000 different products.
  • Backwards compatible. Ports can run in standard I/O (SIO) mode, so a plain binary sensor still works on an IO-Link port.

It adds a second, digital channel alongside the switching signal. The same sensor can still switch, but it can also report values and accept configuration.

CapabilityConventional sensorIO-Link sensor
SignalOn/off or 4-20 mA / 0-10 VOn/off plus digital process data
SettingsPotentiometers, DIP switches, teach buttonParameters set remotely from the PLC or engineering tool
DiagnosticsOften an LED onlyBidirectional: status and extended diagnostics
ReplacementManual re-settingParameters can be restored from a server, so a swapped device is reconfigured automatically
WiringDedicated analogue or digital input per signalOne standard cable per device into an IO-Link master
DocumentationPaper data sheetIODD file

The IO-Link community highlights simple, fast parameterisation and decentralised parameter handling from a server as key advantages, and remote maintenance through the bidirectional communication.

An inductive proximity switch, a typical sensor type for which IO-Link versions with diagnostics are available
An inductive proximity switch, a typical sensor type for which IO-Link versions with diagnostics are availablePhoto: Lucasbosch, CC BY-SA 3.0, via Wikimedia Commons

What is an IODD?

The IODD (IO Device Description) is the file that tells your engineering software what an IO-Link device is. The community describes it as a ZIP file containing the main IODD file, optional language and image files and the manufacturer's declaration. It identifies the device (manufacturer, type, serial number), lists configurable parameters, process data, diagnostic data and communication properties, and so enables automatic recognition and configuration. IODDs are collected in the community's IODDfinder, so you rarely need to hunt through vendor sites.

The IO-Link master translates between IO-Link and the plant network, and the engineering tool uses the IODD to describe the device. The IO-Link community says the master handles the protocol, and the IODD describes the device data model for integration at application level. Specifications exist for PROFINET, PROFIsafe, EtherNet/IP (CIP), EtherCAT, AS-Interface and other systems, plus OPC UA and a JSON integration for IT and cloud use. The community notes that the implementation is most consistent in PROFINET.

A typical workflow in a Siemens project looks like this, though menu names vary by TIA Portal version and master module:

  1. Add the IO-Link master (for example a module in a remote I/O station) to the hardware configuration.
  2. Assign each device to its port, importing its IODD if the catalogue does not already contain it.
  3. Map the process data into PLC tags or use the vendor's function block.
  4. Set parameters from the program or the engineering tool, and enable device replacement features if your master supports them.
  5. Read diagnostics through the normal system diagnostics.

If you want to understand how the master presents data to the controller, see our PROFINET guide.

What else is new: Safety, Wireless and profiles

IO-Link has grown beyond simple sensors. The community states that IO-Link Safety and IO-Link Wireless both arrived in 2022:

  • IO-Link Safety uses IO-Link as a black channel and supports devices and applications up to SIL 3. Safety masters pass the data into PROFIsafe, CIP Safety or FSoE, and IO-Link Safety ports can still run standard devices.
  • IO-Link Wireless replaces the cable with a 2.4 GHz link for flexible installations such as moving parts.
  • Smart Sensor Profiles. SSP 1.2, published on 1 January 2024, standardises more sensor functions such as switching schemes and teach windows, so function blocks can work across vendors.

Because devices can send more than a bit, maintenance can move from fixing breakages to watching trends. The IO-Link community gives an example: IO-Link sensors monitor motor temperature and vibration, the master forwards readings to the cloud using MQTT, and an AI-based system detects anomalies. What a device can report depends on the product; many report status, temperature and operating hours, but check the data sheet and IODD before designing around a particular value.

What is IO-Link?

Use it where the benefits justify the master hardware. Long cable runs beyond 20 metres, very fast high-resolution signals, and plant with a handful of simple on/off sensors may be better served by conventional wiring. Also remember that a PLC program cannot "see" a parameter unless the master, function block and IODD are configured to expose it.

What mistakes should you avoid?

  • Mixing up port classes. Class B ports provide extra power on pins 2 and 5; connecting a device that expects that supply to a class A port will not work, according to the port-class description on Wikipedia.
  • Exceeding 20 metres. Treat the limit as a design rule, not a guideline.
  • Forgetting the IODD. Without the right IODD version, process data may be unreadable or mis-scaled.
  • Not documenting parameters. Record what each device is configured to do, and check whether your master stores parameters for automatic device replacement.
  • Assuming every IO-Link device reports everything. Features vary by manufacturer and product.

Check four things. First, the upstream interface: PROFINET, EtherNet/IP, EtherCAT or another system that matches your controller, and whether it is certified for it. Second, the port count and port classes you need. Third, whether it has an IIoT interface such as MQTT, OPC UA or a REST API if you want data to flow directly to IT systems. Fourth, whether you need safety: IO-Link Safety masters are a separate product category from standard masters.

IO-Link and PROFINET are managed by the same organisation, PI, and the IO-Link community says integration is most consistently implemented in PROFINET. That pairing is why IO-Link is often the first step in a smart-sensor project on a Siemens line: the master appears as a PROFINET IO-Device, and each sensor on it becomes visible to the controller and to diagnostic tools. For IT access, the community lists JSON, REST, MQTT and OPC UA interfaces, so the same sensor data can serve both the PLC and a monitoring platform.

How EDWartens can help

The EDWartens UK Professional Module teaches Siemens TIA Portal PLC, HMI and WinCC SCADA in a five-day live online class, with self-paced Basic Engineering that covers instrumentation, sensors and industrial communication protocols. It is online and simulation-based, so you will not wire a physical IO-Link master on the course; IO-Link configuration is not a dedicated module. Build the background with the free instrumentation course and the instrumentation for PLC engineers course. See also industrial sensors explained and our predictive maintenance guide.

Start free

Learn industrial networks and IIoT free, then practise the job

Free job simulation

PLC Programmer

Write the I/O list, program the line, run the FAT and handle a change request.

The first five days are free, no card needed.

Live UK jobs

IIoT and networks jobs in the UK

Updated daily, with licensed visa sponsors marked.

Browse all engineering jobs

Frequently asked questions

What is IO-Link in simple terms?

IO-Link is a digital communication standard (IEC 61131-9) for the connection between a sensor or actuator and an IO-Link master, using ordinary three-wire cable. It lets a device report diagnostics and receive settings remotely, while the master passes the data to the PLC over a fieldbus or industrial Ethernet.

Is IO-Link a fieldbus?

No. The IO-Link community describes it as an evolution of the three-wire sensor connection, not a fieldbus. It is point-to-point between one device and one master port, and the master connects upward to PROFINET, EtherNet/IP, EtherCAT or other systems. It is fieldbus independent.

What is an IODD file?

An IODD (IO Device Description) is a ZIP package describing an IO-Link device: identification, parameters, process data, diagnostics and communication properties, with optional images and language files. Engineering tools import it to configure the device automatically. Manufacturers publish IODDs, and the IO-Link community runs the IODDfinder database.

How long can an IO-Link cable be?

The standard limits an IO-Link connection to a maximum of 20 metres of unscreened cable, according to Wikipedia's summary of the specification. Ports are class A (up to four pins) or class B (five-pin M12 with extra power). Beyond 20 metres you need another approach, such as placing a master nearer the device.

Can I use a normal sensor on an IO-Link port?

Generally yes. IO-Link ports can work in standard I/O (SIO) mode, so a conventional binary sensor still operates, although it will not provide the digital diagnostics or parameters. Check the master's data sheet for the port configuration options and whether the input type matches your sensor.

Sources

  1. IO-Link Community: Technology
  2. IO-Link Community: Integration
  3. IO-Link Community: IODD
  4. IO-Link Community: Device profiles
  5. IO-Link Community: IO-Link Safety
  6. IO-Link Community: IO-Link and IIoT
  7. PI press release: 2025 node counts (IO-Link 71 million)
  8. Wikipedia: IO-Link (cable length, port classes)
