Industrial Actuators Explained: Motors, Valves and Cylinders

Actuators turn a PLC output into physical motion using electric, pneumatic or hydraulic energy. Industrial pneumatics typically run at about 80 to 100 psi, while hydraulics commonly work at 1,000 to 5,000 psi, which is why hydraulics are chosen when force is the priority. Match the actuator to force, speed, precision and the PLC interface.

ActuatorsMotorsPneumaticsHydraulicsServoIndustrial Automation
Close-up of a collaborative robot arm with a two-finger gripper in a bright workshop

Key takeaways

  • Industrial pneumatics typically run at about 80 to 100 psi, while hydraulics commonly work at 1,000 to 5,000 psi.
  • A four-pole induction motor on 50 Hz has a synchronous speed of 1,500 rpm (120 x 50 / 4), which is why changing frequency changes speed.
  • Steppers usually run open loop (for example 200 steps per revolution) and can lose steps; servos use encoder feedback to avoid that.
  • A 5/2 valve with two cylinder ports is the usual partner for a double-acting pneumatic cylinder.
  • Spring-return valve actuators give a defined fail-safe position on loss of power, a decision to make early in design.

An actuator converts a control signal from a PLC into physical work: a shaft turning, a cylinder extending, a valve opening. There are three energy families. Electric actuators (motors, servos, steppers) suit precision and efficiency, pneumatic actuators suit fast, light, simple motion, and hydraulic actuators suit very high force. Sensors tell the controller what is happening; actuators are how it acts on the answer.

What are the main types of industrial actuator?

The main types are electric, pneumatic and hydraulic, and each is chosen by force, speed, precision and the available utilities. A quick comparison:

ElectricPneumaticHydraulic
Power sourceElectricityCompressed airPressurised oil
Typical working pressuren/aAbout 80 to 100 psi (550 to 690 kPa)Commonly 1,000 to 5,000 psi
StrengthsPrecise, programmable, efficientSimple, fast, forgiving of shockHighest force, stiff and precise
LimitsCost of precision drives; heatAir is compressible, so less stiffLeaks, oil handling, pumps and cooling
Typical useConveyors, pumps, positioningClamping, pick-and-place, valve actuationPresses, injection moulding, heavy lifting

The pressure figures and the point about compressibility come from Wikipedia's article on pneumatics: air is easily compressed, which absorbs shock, whereas hydraulic fluid is practically incompressible and gives precise, stiff motion. For hydraulic cylinders, force equals pressure multiplied by piston area, and measured force can exceed the ideal calculation by 20% or more because of friction (Wikipedia, Hydraulic cylinder).

Which electric motor should you use?

Use an AC induction motor on a variable frequency drive for most general drive duties, a servo for precise closed-loop positioning, and a stepper for simple, lower-cost positioning where missed steps are acceptable. Each answers a different question.

  • Three-phase induction motors are widely used industrial drives because they are self-starting, reliable and economical. Synchronous speed in rpm is 120 x frequency / number of poles, so a four-pole motor on 50 Hz has a synchronous speed of 1,500 rpm, and changing the supply frequency changes the speed (Wikipedia, Induction motor). That is exactly what a drive does; see our VFD guide.
  • Servo motors use position feedback, normally an incremental or absolute encoder, so the controller compares measured and desired position and drives the error to zero. A digital servo drive regulates current, velocity and position with nested feedback loops (Wikipedia, Servomotor).
  • Stepper motors are usually run open loop, a typical example being 1.8 degrees per full step or 200 steps per revolution. Without feedback they can lose steps under heavy load or resonance and end up in the wrong position (Wikipedia, Stepper motor).

Motor efficiency also matters when you are specifying new equipment. IEC 60034-30 defines the IE1 to IE4 efficiency classes (standard, high, premium and super premium), and regulations require minimum classes for many new motors (Wikipedia, IEC 60034-30). Check the rules that apply to your market and motor rating.

Two small aluminium pneumatic cylinders with blue push-in air fittings
Two small aluminium pneumatic cylinders with blue push-in air fittingsPhoto: Grummelbacke, CC BY-SA 4.0, via Wikimedia Commons

How do pneumatic cylinders and valves work together?

A PLC digital output energises a solenoid valve, the valve directs compressed air to one side of a cylinder, and the cylinder moves. A single-acting cylinder has one port and is pushed in one direction by air (usually returning by spring); a double-acting cylinder has two ports, one for the outstroke and one for the instroke. Rodless cylinders have no protruding rod and move a carriage along the body using a mechanical or magnetic coupling, which suits long strokes in confined spaces (Wikipedia, Pneumatic cylinder).

Valves are named by ports and positions. A 5/2 valve has five ports and two positions and is the usual choice for a double-acting cylinder; a 3/2 valve has three ports and two positions and suits a single-acting cylinder. Proportional valves vary flow instead of just switching, but they are fed by an analogue output rather than a simple digital one. This video explains how solenoid valves work and how the coil, plunger and ports interact.

How Solenoid Valves Work - Basics actuator control valve working principle
A pneumatic valve actuator fitted with a solenoid valve on top
A pneumatic valve actuator fitted with a solenoid valve on topPhoto: Pierre.hamelin, CC BY-SA 4.0, via Wikimedia Commons

What about valve actuators in process plants?

Process valves are moved by pneumatic, hydraulic or electric actuators. Compressed air drives pneumatic units on linear or quarter-turn valves; electric actuators use a motor to provide torque and are quiet and efficient but need a power supply; hydraulic actuators convert fluid pressure into motion and can be fitted with fail-safe features (Wikipedia, Valve actuator).

Two points matter for PLC engineers. First, fail-safe behaviour: a spring-return actuator moves the valve to a defined position on loss of power, so the fail-open or fail-closed choice is a process-safety decision made early. Second, positioners: a positioner compares the commanded setpoint with the measured position and drives the actuator until they match, and modern positioners self-adapt. Analogue positioners are commanded by a 4-20 mA output; the signal basics are in our sensors guide.

How do actuators connect to a PLC?

There are four common interfaces:

  1. Digital outputs: simple on/off control of contactors, solenoid valves and lamps. Check the output card's current rating; use interposing relays for larger coils.
  2. Analogue outputs: 4-20 mA or 0-10 V commands to positioners and drives.
  3. Fieldbus and IO-Link: PROFINET, IO-Link or AS-Interface devices report diagnostics as well as taking commands. See the PROFINET guide.
  4. Motion interfaces: pulse-train or fieldbus-based servo and stepper control for precise positioning. For robot cells, see robotics and PLC integration.

How do you size a pneumatic cylinder?

Use force = pressure x piston area, then add a generous margin. The same relationship that Wikipedia gives for hydraulic cylinders (F = P x A, ignoring friction) applies to pneumatics, and the industrial supply pressure quoted above is about 6 bar.

Worked example in plain text: a cylinder with a 50 mm bore has a piston area of 3.14159 x 0.025 x 0.025 = 0.001963 square metres. At 6 bar (600,000 pascals) the theoretical push force is 600,000 x 0.001963 = about 1,178 newtons, roughly 120 kg-force. Seal friction, supply-pressure drops under flow and acceleration all reduce what is available, so choose a bore where the real load is a comfortable fraction of the theoretical force and follow the manufacturer's sizing tool. On the retract stroke of a double-acting cylinder the rod takes up area, so pull force is lower than push force for the same pressure.

Speed is normally set with flow-control valves on the exhaust side, not by the PLC. The PLC's job is to switch the valve and check the result: fit end-of-stroke sensors, give each movement a time-out, and raise an alarm if a position is not reached within the expected time. A cylinder that is slow to arrive is often the first visible sign of a worn seal, a restricted air line or a failing solenoid.

How do you choose an actuator?

Start from the load and work outwards:

  • Force or torque needed at the worst point of the stroke, with margin for friction.
  • Speed and cycle rate, including acceleration limits.
  • Precision and holding: servo or hydraulic for stiff positioning; pneumatic for end-to-end motion.
  • Environment: washdown, temperature, explosive atmospheres.
  • Utilities and lifetime cost: compressed air is convenient but its generation is an energy cost, so look at the whole-life cost and not only the purchase price.
  • Safety function: if the actuator is part of a stop function, check the architecture against ISO 13849-1 performance levels with your safety engineer.

How EDWartens can help

The Professional Module is a five-day live online Siemens TIA Portal class that teaches you to switch outputs from ladder logic, test them in PLCSIM and build HMI and WinCC screens. Self-paced Basic Engineering includes modules on pneumatics and hydraulics, and on control systems and automation. The course is online and Siemens-focused, so you will simulate actuators rather than connect them to a physical rig. Try the motor control simulator and the free pneumatics and hydraulics course, then see the Professional Module.

Start free

Learn PLC programming free, then practise the job

Free job simulation

PLC Programmer

Write the I/O list, program the line, run the FAT and handle a change request.

The first five days are free, no card needed.

Live UK jobs

PLC and automation jobs in the UK

Updated daily, with licensed visa sponsors marked.

Browse all engineering jobs

Frequently asked questions

What is the difference between pneumatic and hydraulic actuators?

Pneumatic actuators use compressed air, typically at about 80 to 100 psi, and are simple and fast but less stiff because air compresses. Hydraulic actuators use oil at far higher pressure, commonly 1,000 to 5,000 psi, giving much more force and stiffer positioning at the cost of leaks, pumps and oil handling.

Should I choose a servo motor or a stepper motor?

Choose a servo when you need guaranteed position under varying load, because it uses encoder feedback and a drive that closes the loop. Choose a stepper for lower-cost positioning with predictable loads, accepting that open-loop steppers can lose steps under heavy load or resonance without the controller knowing.

How does a PLC control a double-acting pneumatic cylinder?

The PLC energises a solenoid on a 5/2 valve, which sends air to one cylinder port while venting the other, extending the cylinder. De-energising or energising the opposite coil reverses the flow and retracts it. Position sensors on the cylinder usually feed back to PLC inputs to confirm each end of stroke.

What does fail-safe mean on a valve actuator?

It means the valve moves to a defined position, open or closed, when power or air is lost. A spring-return actuator does this mechanically. The correct failure position depends on the process hazard, so it should be chosen with the process safety team, not left to the default catalogue option.
